JLDN1612-A laser cutting machine performance parameters
Laser type: Sealed-off carbon dioxide laser
Working stroke: 1220 * 1620 mm
Optical path forms: fixed optical (laser cutting head is fixed, plate movement)
Transmission: precision ball screw drive, motor and screw directly connected
Cutting material and thickness: wood 6-22mm, PVC sheet, acrylic and other non-metallic materials
Ambient temperature: 5 degrees -35 degrees
Cooling water temperature: 5 ° to 30 °
Cooling water: Pure water
Shielding gas: oil-free compressed air drying
Relative humidity: ≤ 80%
Power supply: single-phase 220V ± 5% 50HZ 15 A (machine + chiller) +10 A (blower)
Cutting speed: 0-3000mm/min software settings (18mm planks :45-55cm / min)
Positioning accuracy: ± 0.05mm
Repeatability: ± 0.02mm
NC panel: LCD display, Chinese and English operation interface, touch switch
Transmission Interface: network cable connection, offline operation, the device can be individually placed
Instruction: International standard, compatible with CDR, CAD and other software
Control Software: Gaylord laser precision die cutting system (in English)
Machine dimensions: 4000mm (or so) * 3900mm (front and rear)
Working area: 6000mm * 5000mm
Machine weight: 1.7 t
